Brushless DC Motor/UAV Motor 2212

2212

Support 3-4S lithium battery, peak current 14A, thrust range 600-1200g, speed up to 16000rpm. Rotational motion, used for civil drones, aviation models, wind blade loads. Applications: 1. Civilian aerial photography drones, multi-axis rotary wing aircraft models. 2. Hair dryers for garden tools. 3. Storage environment: ambient temperature (-15°C~70°C), humidity (10%~90%).
Performance parameters Motor model Unit WFDBL2212 （KV840） WFDBL2212（KV1400） No-load current A 0.5 0.9 Maximum current A 14 18 Maximum power W 155 199 Operating voltage (Lipo) S 3-4S 2-3S Maximum efficiency ％ ＞85 ＞83 Recommended ESC 15A 20A Motor resistance Ω 0.1945 0.0886 Propeller configuration 1045/1145 8040/8060 Thrust g 600-1000 800-1200 Motor weight g 53 53 Motor size mm φ28*24.3 φ28*24.3
