Brushless DC Motor/UAV Motor/Electric Scooter Motor

5065

Supports 4-8S lithium battery, peak current 75A, thrust range 3000-6000g, speed up to 13000rpm. Rotational motion, used for civil drones, aviation models, wind blade loads, electric scooters with speeds below 40KM/h. Applications: 1. Civilian aerial photography drones, fixed-wing aircraft models. 2. Hair dryers for garden tools. 3. Electric scooters. 4. Storage environment: ambient temperature (-15°C~70°C), humidity (10%~90%).
Performance parameters Motor model Unit WFDBL5065 （KV270） WFDBL5065 （KV430） No-load current A 1 2.6 Maximum current A 60 75 Maximum power W 1776 2220 Operating voltage (Lipo) S 4～8S 4～8S Maximum efficiency ％ ＞85 ＞85 Recommended ESC 70A HV-80A Motor resistance Ω 0.0341 0.0219 Propeller configuration 〞 20〞/22〞 16〞/17〞 Thrust g 3000～5500 3000～6800 Motor weight g 350 350 Motor size mm φ50*65 φ50*65
